Description
Parameter
Maximum thrust 1500KG Maximum self-latching force reaches 1800KGSInner extension tube is made by stainless steel, which is more firm Maximum speed reaches 63mm/s Potential meter or Hall output signal feedback is optional Meet IP66 standard, suitable for outdoor applicationUsing 48V/36V/24/12V electric motor With clutch system, and overload protection Be able to be applied in various industrial and agricultural vehicles which work in harsh environment Suitable for heavy load application, and maintenance-free
| 傳動代碼 |
傳動比 |
最大載荷（N） |
轉速（Rpm） |
速度mm/s±10% |
12V |
24V |
36V |
48V |
| 空載 |
滿載 |
滿載 |
滿載 |
滿載 |
滿載 |
| ACME |
|
|
|
|
|
電流 |
電流 |
電流 |
電流 |
| R7 |
110:1 |
12000 |
2100 |
1.3 |
1 |
12 |
6 |
4.5 |
3.2 |
| R6 |
110:1 |
10000 |
4000 |
3 |
2 |
12.5 |
6.5 |
5 |
3.5 |
| R5 |
40:1 |
8000 |
2100 |
3.5 |
2.5 |
11 |
6 |
4.5 |
3.5 |
| R4 |
40:1 |
7000 |
4000 |
6.5 |
4.5 |
15 |
8 |
6 |
3.5 |
| R3 |
20:1 |
3500 |
4000 |
12.5 |
8.5 |
16 |
7.5 |
5.5 |
3.5 |
| R2 |
10:1 |
2000 |
4000 |
23 |
16 |
16 |
8 |
6 |
3.5 |
| R1 |
5:1 |
1200 |
4000 |
50 |
35 |
16.5 |
8 |
6 |
3 |
| Ball screw |
|
|
|
|
|
|
|
|
|
| T7 |
110:1 |
15000 |
2100 |
1.5 |
1 |
8 |
3.5 |
2.3 |
2 |
| T6 |
110:1 |
13000 |
4000 |
3.5 |
2.5 |
7.5 |
3.5 |
2.5 |
1.8 |
| T5 |
40:1 |
12000 |
2100 |
4 |
3 |
8 |
3.5 |
2.5 |
2.1 |
| T4 |
40:1 |
10000 |
4000 |
8 |
5.5 |
12 |
6 |
4 |
2.8 |
| T3 |
20:1 |
5000 |
4000 |
16.5 |
12 |
11 |
6 |
4 |
2.6 |
| T2 |
10:1 |
3000 |
4000 |
32 |
24 |
11 |
6 |
4 |
2.7 |
| T1 |
5:1 |
1700 |
4000 |
62 |
45 |
11 |
6 |
4 |
2.6 |
